High precision Jewelry Laser Cutting Machine for Gold Silver Brass Pendant Name Necklace

Fast speed and high precision jewelry laser cutting machine for gold silver jewelry in china


High precision Jewelry Laser Cutting Machine for Gold Silver Brass Pendant Name Necklace
fiber laser cutter

Features of Jewelry Laser cutting machine
1. Ball screw transmission way, improve metal cutting precision.
2. Excellent Path Quality: Smaller laser dot and high work efficiency, high quality.
3. High Cutting Speed: cutting speed is 2-3 times than same power laser cutting machine.
4. Stable Running: adopt top world fiber lasers generator, stable performance, key parts can reach 100,000 hours.
5. High Efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.
6. Low Cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.
7. Low Maintenance: fiber line transmission no need reflect lens, save maintenance cost;
8. Easy Operations: fiber line transmission, no adjustment of optical path.

Laser cutting systems can cut a wide variety of materials of varying thickness and are well suited for creating complex shapes. In addition, fiber lasers maximize precision, cut flexibility and throughput and offer a cost effective high accuracy cutting solution while at the same time providing jewelry designers freedom to create challenging shapes unconstrained by traditional cutting methods.


Below are just a few advantages of laser cutting machines compared to traditional cutting methods:


Minimal distortion on parts due to a small heat affected zone

Intricate part cutting

Narrow kerf widths

Very high repeatability

With a laser cutting system you can easily create complex cutting patterns for your jewelry designs:


Interlocking Monograms

Circle Monograms

Name Necklaces

Complex Custom Designs

Pendants & Charms

Intricate Patterns

Custom One-Of-A-Kind Parts

Applicable Material Metal
Condition New
Laser Type Fiber Laser
Cutting Area 300mm*300mm,600mm*800mm
Cutting Speed 30m/min
Graphic Format Supported AI, PLT, BMP, Dst, Dwg, LAS, DXP
Cutting Thickness 5mm
CNC or Not Yes
Control Software Cypcut
Laser Source Brand JPT 1000W 1500W 2000W
Laser Head Brand Raytools
Servo Motor Brand Panasonic Servo motor
Guiderail Brand HIWIN
Control System Brand Cypcut
Weight (KG) 500KG
Key Selling Points High Productivity
Applicable Industries Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company

Applicable materials:Used for cutting gold,silver,carbon steel, silicon steel, stainless steel, aluminum alloy, titanium alloy,galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials cutting and so on.
Applicable industries:Applied in high precision apparatuses,aluminum copper clad laminates, machinery, electrical apparatuses, metal crate and cabinet, electric appliance shell, metal plate processing,sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries.

Laser Cutter Samples
laser cutter jewelry

metal cutter
jewelry cuttingcopper brass cutting

Details Parts
fiber laser cutterlaser cutter

Q: Do you have FDA CE document and other documents for customs clearance?
A: Yes, we have FDA CE, Provide you with a one-stop service.At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.

Q: Why the machine price not include fiber source?
Different customers, different requirements, and many different laser power can be optional, that's why we list the price not include fiber source parts.

Q: If we are interested in your machine, how to choose proper power?
Please tell us the following answer, our professional seller will recommend you proper power.
1. What material you want to cut,stainless steel,carbon steel or other?
2. What thickness do you want to cut?

Q: How about warranty?
A: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the
world, We need your machines running in order to keep your business
