100w 3D dynamic large format co2 laser marking machine for paper card, leathe cutting

2020 new style 3d dynamic laser marking machine with addordable price from hiteccnc Large working format for paper card cutting, leather shoes cutting

MODEL: HTJ-100C-3D
BRAND: HITEC
VIEWS:

100w 3D dynamic large format co2 laser marking machine for paper card, leathe cutting
Co2 laser marking machine

laser marking machine for sale
Advantage of 100w 3D dynamic laser marking machine
1. Equipped with hi-tech dynamic focusing galvo scanner
2. High-precision and high-speed laser marking & laser engraving.

3. Co2 Dynamic Focusing Laser Marking Engraving Machine is equipped with RF laser tube imported from America.
The RF Co2 Laser can work in large power with high frequency and long operating life.

4. Equipped with hi-tech dynamic focusing scanning mirror and control card, the 3 Axis Dynamic Laser Machine system is excellent in the aspects of algorithm optimization, high speed of marking and cutting, and other powerful functions. It is specially designed for the laser scanning with a tiny light spot, large working range, and high flexibility.Furthermore, this 3 Axis Co2 laser marking equipment is characterized by high strength in use, compact construction, dust-proof, convenient and accurate installation, strong anti-jamming ability, etc., which can ensure the stability of the system under long-hours working conditions.

100w CO2 Dynamic Laser Marking Machine Feature
◆Fully enclosed laser optic system doesn’t need adjustment and is maintenance-free.
◆Original imported metal RF laser enjoys the high power and good beam quality, stable power output and long lifetime(above 20k hours).
◆ 3 axes laser scanning system has a compact structure, rugged dust-proof, precise, anti-interference.


Application materials
HITEC 2020 new style co2 laser marking machine suitable for almost all non-metal materials, including paper card, leather, rubber, wood board, bamboo products, organic glass, ceramic tile, plastics, marble, jade, crystal, cloth, etc.

Applicable Industry
100w large format 3d dynamic co2 laser marking machine  is used to paper arts & crafts, leather products, glasses, clothing, bamboo and wood products industry, package, advertising decoration and architectural model.

2020 new style 3D dynamic laser marking machine parameters

Brand HITECCNC®
Laser Type co2 laser
 Laser Power 100W
 Model HTJ-100W-3D
 Laser Wavelength 1064nm
 Marking Area 600*600mm
 Marking Depth ≤1.2mm
 Marking Speed 10000mm/s
 Minimum Line Width 0.012mm
 Minimum Character 0.15mm
 Repeated Precision ±0.003mm
 Life-span of Fiber Laser Module 100 000hours
 Beam Quality M2 <1.5
 Focus Spot Diameter <0.01mm
 Output Power of Laser 10%~100% continuously to be adjusted
System Operation Environment Windows XP /7/8/10 32/64bits
Temperature of Operation Environment 15℃~35℃
 Power Input 220/110v single phase
 Power Requirement <400W
 Communication Interface USB
Machine Dimension/after package 2000*850*1360mm
 Optional Rotary Device, Moving Table, other customized Automation
Price Range $4200-$9800

Details Parts with Co2 laser 3D dynamic

1. Large format 600*600mm working area
large format working area

2. Up-down table
up-down life tablelift table

3. Large format working table
large screen working table

4. Computer with Co2 laser marking machine
laser marking machine with computer

5. Co2 laser marking switch
switch

6. Dust collect
dust collect


Samples of Co2 laser marking machine
coconut laser marking machinepaper laser cutting machine3d dynamic laser marking machine




Tag:  laser marking machine  co2 laser marking machine  dynamic laser marking machine  3d dynamic laser marking machine  laser marking machine for paper cutting  laser marking machine for leather cutting  laser marking machine with large format
